Features
The tubes in this series are produced with plasticized flexible 12 PHL polyamide, stabilized in light and heat and stored in our warehouses in 6 m straight bars. Equipped with the flexibility characteristic of this material, they also enjoy excellent resistance to abrasion and aging. We produce a range of diameters covering from the inner Ø 44 mm to 110 mm.
Standard lengths
6 m bars (tolerance on cut -0/+50 mm)
On demand
We produce food polyamide bars. We tailor the bar to facilitate its transport.
Sector
INDUSTRIAL
FOOD
Applications
Products & Details
Pressure & temperature
Operating temperature: from -40°C to 80°C
Safety factor on working pressure: 3:1
