Features
Multi-tube made with PELD polyethylene inner tubes and black polyethylene sheath. The cheapest solution to organize low pressure pneumatic systems or to transport fluids that are resisted by low density polyethylene.
Sector
INDUSTRIAL
Applications
INDUSTRIAL AUTOMATION
CHEMICAL RESISTANCE
VACUUM
Products & Details
MULTITUBES CONFIGURATION
| COD | 2 | 3 | |
| STANDARD* | S |  |  |
| LINEAR** | L | – |  |
| COLORS | T-BS | T-R-BS |
** the codes relating to the STANDARD multitubes a
3 tubes refer respectively to T
(triangular) for the three tubes .
2-PIPES MULTITUBE
| Internal Ø (mm) | External Ø (mm) | Minimum bending radius (mm) | Maximum working pressure (BAR) | STANDARD (mm) | |
| MTP2X4X2 | 2 | 4 | xx | 21 | 9×5 |
| MTP4X6X2 | 4 | 6 | xx | 12 | 13×7 |
| MTP6X8X2 | 6 | 8 | xx | 9 | 16×10 |
| MTP8X10X2 | 8 | 10 | xx | 7 | 22×12 |
3-PIPES MULTITUBE
| Internal Ø (mm) | External Ø (mm) | Minimum bending radius (mm) | Maximum working pressure (BAR) | STANDARD (mm) | TRIANGLE (mm) | |
| MTP4X6X3 | 4 | 6 | xx | 12 | 20×8 | 14×14 |
| MTP6X8X3 | 6 | 8 | xx | 9 | 26×10 | – |
Pressure & temperature
Operating temperature: from -10°C to 60°C
Safety factor on working pressure: 3:1
